Toll Processing
Strategically Midwest-Focused
Left to Right: Chicago Plant, Grandville Plant, Wayne Plant
Chicago Plant
14100 S. Halsted Street
Chicago, IL 60827
Phone: (708) 765-4075
Fax: (708) 765-4075
Shipping/Receiving Hours: Monday – Friday: 6am – 4pm
*Or by Special Appointment
Grandville Plant
4165 Spartan Industrial Drive SW
Grandville, MI 49418
Phone: (616) 531-8600
Fax: (616) 531-7555
Shipping/Receiving Hours: Monday – Friday: 7am – 9pm
*Or by Special Appointment
Wayne Plant
5501 Belleville Road
Canton, MI 48188
Phone: (734) 590-3003
Fax: (734) 590-3003
Shipping/Receiving Hours: Monday – Friday: 6am – 2:30pm
*Or by Special Appointment
Equipment Capabilities
Grandville Plant
145,000 sq. ft Climate Controlled Facility in Grandville, MI
24" Slitter
24″ Slitter
• Material Thickness: .020”-.200”
• Max Entry and Exit Weight: 15,000lbs
• Min/Max Entry Width: 1.00“/24.00”
• Min/Max Exit Width: .500”/24.00”
• Max Entry OD: (60 ID 20) (55 ID 24)
• Max Exit OD: 59
• Min/Max Entry ID: 20/24
• Min/Max Exit ID: 20/24
36" Slitter
36″ Slitter
• Material Thickness: .015”-.100”
• Max Entry and Exit Weight: 15,000lbs
• Min/Max Entry Width: 1.00“/36.00”
• Min/Max Exit Width: .800“/36.00”
• Max Entry and Exit OD: 60
• Min/Max Entry ID: 16/20
• Min/Max Exit ID: 16/20
60" Slitter
60″ Slitter
• Material Thickness: .020”-.130”
• Max Entry and Exit Weight: 30,000lbs
• Min/Max Entry Width: 1.00“/60.00”
• Min/Max Exit Width: .500”/60.00”
• Max Entry OD: 68
• Max Exit OD: 65
• Min/Max Entry ID: 20/24
• Min/Max Exit ID: 20/24
72" Slitter
72″ Slitter: Wave Correction Cluster Leveler
• RB20-RB60 – Any Type of Wave
• RB60-RB80 – Light/Med Wave
• Material Thickness: .012”-.250”
• Min/Max Entry Width: 5.00”/74.00”
• Min/Max Exit Width: 1.00”/72.00”
• Min and Max Entry/Exit OD: 74
• Min/Max Entry ID: 20/24
• Min/Max Exit ID: 20/24
East Blanker
East Blanker
• Material Thickness: .015”-.100”
• Max Entry Weight: 40,000lbs
• Max Entry and Exit Width: 72.00”
• Min Entry and Exit Width: 2.00”
• Max Entry OD: 66
• Min/Max Entry ID: 20/24
• Max Length: 192”
• Max Number of Cuts: 2 Cuts
West Blanker
West Blanker
• Material Thickness: .100”-.250”
• Max Entry Weight: 40,000lbs
• Max Entry and Exit Width: 40.00”
• Min Entry and Exit Width: 2.00”
• Max Entry OD: 72
• Min/Max Entry ID: 24
• Max Length: 144”
Cold Reduction Line
Cold Reduction Line: Safety Edge, Round Edge
• Material Thickness: .080”-.375”
• Max Entry and Exit Weight: 10,000lbs
• Max Entry and Exit Width: 10.00“
• Min Entry and Exit Width: 2.00”
• Max Entry and Exit OD: 70
• Min/Max Entry ID: 16/20/24
• Min/Max Exit ID: 20/24
Debur Line
Debur Line: Decamber/Leveling
• Max Gauge for Decamber/Recoil: .200”
• Max Gauge for Leveling: .180“
• Material Thickness: Min .030”/.200“
• Max Entry and Exit Weight: 4000lbs
• Max Entry and Exit Width: 2.50”
• Min Entry and Exit Width: .500”
• Max Entry and Exit OD: 72
• Min/Max Entry ID: 16/20/24
• Min/Max Exit ID: 20/24
Shears
Shears
• Material Thickness: .020”-.500”
• Min Width: 1.00”/4.00”
• Max Width: 144.00”/120.00”
Wayne Plant
280,000 sq. ft Climate Controlled Facility in Canton, MI
Slitting
72”, 60 Flex (60” & 72” heads), 48” Heavy Gauge, 30”
• Material Thickness: .016”-.500”
• Incoming Width: 2.00”-74.00”
• Slitting Width: .500”-72.00”
• Incoming ID: 20”-28”
• Incoming Max OD: 72.00”
• Outgoing ID: 20” and 24”
• Incoming Coil Weight: 60,000lbs max
• Outgoing Coil Weight: 50,000lbs max
Blanking
36” Blanker
• Material Thickness: .030”-.250”
• Max Incoming Width: 36.00“
• Min Incoming Width: 2.50”
• Incoming Max OD: 72.00“
• Incoming Coil ID: 20” or 24”
• Max Entry Weight: 10,000lbs
• Max Exit Weight: 5,000lbs
Cut To Length
72″ Line
• Material Thickness: .060”-.250”
• Incoming Width: 6.500”-72.00”
• Incoming Max OD: 75.00”
• Incoming Coil ID: 20” or 24”
• Max Incoming Weight: 50,000lbs
• Length (Min/Max): 10.00”-192.00”
• High strength and high gauge reduces width
capacity.
Cold Reduction Mill
24″ 4Hi Mill
• Material Thickness: .030”-.250”
• Max Incoming Width: 17.00”
• Incoming Coil ID: 20” or 24”
• Incoming and Exit OD: 72.00” max
• Max Entry Weight: 20,000lbs
• Max Exit Weight: 12,000lbs
• Automatic Thickness Control – Feed Forward
Gauge Control Program: Tolerances +/- .001”
Histogram and Thickness Profile
Stretcher Levelling
72″ Sretcher Leveller
• Material Thickness: .020”-.312”
• Incoming Coil ID: 19.00”-25.00”
• Max Incoming Width: 75.00”
• Max Incoming Coil OD: 84.00”
• Max Incoming Coil Weight: 50,000lbs
• Max Sheet Length: 240.00”
• Max Sheet Exit Weight: 20,000lbs
• Max Sheet Exit Height: 24” (Including Skid)
Shear
Wysong Shear
• Material Thickness: .025”-.250”
• Max Width: 120.00”
• Min Width: 1.00”
• Max Length: 72.00”
• Min Length: 4.50”
Chicago Plant
60,000 sq. ft Climate Controlled Facility in Chicago, IL
60" Slitter
60″ Slitter
• Material Thickness: .008”-.125”
• Incoming Width: 1.00”-60.00”
• Slitting Width: .500”-60.00”
• Incoming ID: 20”-24”
• Outgoing ID: 16”/20”/24”
• Incoming Max OD: 72”
• Outgoing Max OD: 69”
• Incoming & Outgoing Max Coil Weight: 48,500lbs
48" Slitter
48″ Slitter
• Material Thickness: .015”-.120”
• Incoming Width: 1.00”-48.00”
• Slitting Width: .800”-48.00”
• Incoming ID: 20”-24“
• Outgoing ID: 16”-20”
• Incoming and Outgoing Max OD: 72”
• Incoming and Outgoing Max Weight: 20,000lbs
Slear
DBI Line
• Material Thickness: .020”-.105”
• Incoming Min Width: 21.00”
• Incoming Max Width: 68.00”
• Outgoing Min Slit Width: 3.00”
• Outgoing Max Slit Width: 68.00”
• Outgoing Min Length: 11.00”
• Outgoing Max Length: 143.00”
• Incoming Max Coil Weight: 48,500lbs
• Outgoing Max Bundle Weight: 10,000lbs
• Outgoing Max Bundle Height: 24.00”
• Max Number of Cuts on Slear: 7
